3: Management & Configuration
6. Delete any existing interfaces with the following commands:
interface delete Management
interface delete Network
7. The Network port of EtherNID #1 will be used for the in-band management. Configure the Network port with the
following command:
interface add net1-10 type vlan vlan1-id 10 port Network address 192.168.1.253 netmask
255.255.255.0
8. Repeat configuration steps 1 to 7 on EtherNID #3 using the following settings when defining the new interface:
interface add net3-10 type vlan vlan1-id 10 port Network address 192.168.1.252 netmask
255.255.255.0
9. Repeat configuration steps 1 to 6 on EtherNID #2.
10. Execute the following commands to add three interfaces on EtherNID #2:
interface add mgmt type standard port Management
interface add cli10 type vlan vlan1-id 10 port Client
interface add net10 type vlan vlan1-id 10 port Network
The interface 'mgmt' will be used to connect to the management bridge. The other two interfaces will be used to
access the other two EtherNIDs remotely.
11. Next, create the bridge interface. Execute the following command to bridge all three interfaces together for access
using the Management port.
interface add Bridge type bridge sub-intf mgmt,cli10,net10 address 192.168.1.254 netmask
255.255.255.0
12. Connect the Management port of EtherNID #2 to the private network.
13. Open a web browser on a computer connected to the private network and enter the address 192.168.1.254 to
reach the management web interface on EtherNID #2.
14. Connect the Client port of EtherNID #2 to the Network port of EtherNID #3.
15. Connect the Network port of EtherNID #2 to the Network port of EtherNID #1.
16. Open a web browser and enter the address 192.168.1.254 to reach the management web interface on EtherNID
#2.
17. Open a second web browser and enter the address 192.168.1.253 to reach the management web interface on
EtherNID #1.
18. Open a third web browser and enter the address 192.168.1.252 to reach the management web interface on
EtherNID #3.
