Aerotech Ensemble HLe - Table 6-2: Fuse Information

Maintenance Ensemble HLe
Table 6-2: Fuse Information
Fuse Drive Size Aerotech P/N Manufacturer's P/N
F1,
F2
10-40 5A S.B. EIF01023 Littelfuse 215005.P
20-40 10A S.B. EIF01020 Littelfuse 215010.P
10-60 5A S.B. EIF01023 Littelfuse 215005.P
10-80 5A S.B. EIF01023 Littelfuse 215005.P
F3 Line voltage dependent, see Table 6-3
EIF01023 (5 AFuse) Littelfuse 215005.P
EIF01020 (10 A Fuse) Littelfuse 215010.P
Table 6-3: Line Voltage Fuse Information
Line Voltage Fuse F3 Value
100V(C) 10A SB
115V (A) 10A SB
200V (D) 5A SB
230V (B) 5A SB
