Aerotech Ensemble HLe User Manual

70 Chapter 3 www.aerotech.com
Table 3-1: -IO Expansion Board Jumper Configuration
Jumper Setting Description
JP2
1-2 PSO Output Active High, Low Z during reset
2-3
(1)
PSO Output Active Low, High Z during reset
JP3
1-2, 3-4 Switch Brake +
5-6, 7-8
(1)
Switch Brake -
1-3 Relay Only
(1) default
Table 3-2: -IO Option Board Fuse Information
Fuse Description Size Aerotech P/N Manufacturer's P/N
F1 +5 VDCUser Power 3A, resettable EIF01001 Raychem RGE300
Ensemble HLe -IO Expansion Board
