Maintenance Ensemble HLe
Chapter 6: Maintenance
D A N G E R : Always disconnect the Mains power connection before opening the Ensemble
HLe chassis.
D A N G E R : Before performing any tests, be aware of lethal voltages inside the controller and
at the input and output power connections. A qualified service technician or electrician should
perform these tests.
Table 6-1: LEDîDescription
LED Description
ENB/FLT
Turns green to indicate that the axis is enabled. Turns red to indicate a fault condition. The
ENB/FLT LED will flash between RED and GREEN if the drive is enabled and in a fault
condition.
MARKER Turns green to indicate that the marker input is high.
PWR* Turns green when power is applied.
POS Turns green to indicate that the axis is in position.
* If the power light flashes continuously and the unit does not operate, there is too much current draw from the 5V power supply or
the control supply voltage level is low.
www.aerotech.com Chapter 6 99
