Maintenance Ensemble HLe
Table 6-5: Control Board Fuse Information
Fuse Description Size Aerotech P/N Manufacturer's P/N
F1 Radial Lead Resettable Fuse 3A EIF01001 Raychem RGE300
F2 Surface Mount Fuse .05A EIF01028 Raychem MICROSMD005F-2
F3 Surface Mount Fuse .05A EIF01028 Raychem MICROSMD005F-2
F4 Surface Mount Fuse .05A EIF01028 Raychem MICROSMD005F-2
F5 Surface Mount Fuse .05A EIF01028 Raychem MICROSMD005F-2
F6 Resettable Fuse .5 A EIF01002 Raychem MINISMDC050
Table 6-6: LEDDescription
LED Description
ENB/FLT
Turns green to indicate that the axis is enabled. Turns red to indicate a fault condition. The
ENB/FLT LED will flash between RED and GREEN if the drive is enabled and in a fault
condition.
MARKER Turns green to indicate that the marker input is high.
PWR* Turns green when power is applied.
POS Turns green to indicate that the axis is in position.
* If the power light flashes continuously and the unit does not operate, there is too much current draw from the 5V power supply or
the control supply voltage level is low.
www.aerotech.com Chapter 6 103
