Aerotech Ensemble HLe - Table 5-2: Cable Part Numbers

Ensemble HLe Accessories
Figure 5-4: Two Axis Joystick Interface (to the I/OBoard)
Table 5-2: Cable Part Numbers
Part # Cable Description UPC#
C227712-XX JSXT-FLY 26HD-15DU-MAX300DM ENSEMBLEHLE DUAL AXIS 630B2277-12
C227713-XX JSXT-26HD-15DU-MAX300DM ENSEMBLEHLE SINGLE AXIS 630B2277-13
C227714-XX JSXT-26HD 26HD-15DU-MAX300DM ENSEMBLEHLE DUAL AXIS 630B2277-14
C227716-XX JSXT-FLY-15DU-MAX 300 DM ENSEMBLEHLE DUAL AXIS 630B2277-16
96 Chapter 5 www.aerotech.com
