Aerotech Ensemble HLe User Manual

Installation and Configuration Ensemble HLe
2.5.4. Digital Inputs 0-3 (J205)
The digital inputs are opto-isolated and may be connected to current sourcing or current sinking devices, as
shown in Figure 2-30 and Figure 2-31. These inputs are designed to connect to other ground-referenced
circuits and are not intended for high-voltage isolation.
The opto-isolator's common connections can be directly connected to the drive's power supply; however,
doing so will effectively defeat the isolation and will reduce noise immunity.
Table 2-30: Digital Input Specifications
Input Voltage Approximate Input Current Turn On Time Turn Off Time
+5 V 1 mA 200 usec 2000 usec
+24 V 6 mA 4 usec 1500 usec
Table 2-31: Port 0 Digital Input Pins on the Auxiliary I/O Connector (J205)
Pin# Description In/Out/Bi
17
Digital Input 0 / CCW EOT Input
(1)
Input
18
Digital Input 1 / CW EOT Input
(1)
Input
24 Input Common -
25
Digital Input 2 / Home Input
(1)
Input
26 Digital Input 3 Input
(1) Software configured option
www.aerotech.com Chapter 2 59
