Agilent Technologies 6890 Series Service Manual

19 of 26
Jun 2001
Detectors
Agilent 6890 Gas Chromatograph Service Manual
Micro-cell Electron Capture Detector (µ-ECD) 341
Replacement procedures
Figure 341-15 Removing the top cover and anode signal wire
4. Remove the screw and clamp on the electrical interconnect.
5. Remove one Torx T-20 screw from each end of the signal board. (Do not
remove the screw on the top of the cover.)
Remove detector
top cover
Remove anode signal wire
