Agilent Technologies 6890 Series - Page 332

21 of 26
Jun 2001
Detectors
Agilent 6890 Gas Chromatograph Service Manual
Micro-cell Electron Capture Detector (µ-ECD) 341
Replacement procedures
Figure 341-17 Location of detector interface board (board installed in back detector
position)
Detector card screw
Ribbon cable
µ-ECD detector board
