23 of 36
Jun 2001
Detectors
Agilent 6890 Gas Chromatograph Service Manual
Flame Photometric Detector (FPD) 350
Replacement procedures
Figure 350-13 Replacing the ignitor glow plug
6. Remove the ignitor cable.
7. Unscrew the connector and ignitor assembly from the detector module.
8. Remove the O-ring, ignitor spacer, and glow plug from the ignitor
assembly. Replace the glow plug. Inspect the O-ring and spacer, and
replace if needed.
9. Reassemble in reverse order.
Glow plug
Ignitor cable
O-ring
Spacer
Connector
Ignitor cable
