1210 External Connectors, 6890A and 6890 Plus
Modular Input/Output (MIO) INET
12 of 14
Jun 2001
Electrical
Agilent 6890 Gas Chromatograph Service Manual
Modular Input/Output (MIO) INET
ET Input connector
Pin Function In/Out
1 IN1 INPUT
2 IN2 INPUT
INET Output connector
Pin Function In/Out
1 OUT1 OUTPUT
2 OUT2 OUTPUT
IN1
IN2
OUT1
(no pin)
OUT2
