Agilent 6890 Gas Chromatograph Service Manual
Main Board, 6890A and 6890 Plus 1220
Circuitry diagrams
Figure 1220-6 Heater driver circuitry
GROUND
HTRPWR_FRNT
6|INJ_FRNTc
lnOVC_FAULT
