Agilent 7100 Capillary Electrophoresis System User Manual 21
Site Requirements and Specifications 2
Physical Specifications
Physical Specifications
For applications run in CEC mode (Capillary Electrochromatography) or CE+p
mode (Capillary Electrophoresis mode with optional usage of higher pressure), an
external pressure supply of oil-free air or nitrogen with a maximum pressure of 15
bar (218 psi) can be used. A respective male adapter that fits into the instrument’s
female adapter and PTFE tubing are part of the shipment.
Table 2 Physical specifications
Type Specification Comments
Weight 35 kg (77.2 lbs)
Dimensions
(width × depth × height)
350 x 510 x 590 mm
(13.8 x 20.1 x 23.2 inches)
Line voltage 100–240 VAC ± 10% Wide-ranging capability
Line frequency 50 or 60 Hz ± 5%
Power consumption 350 VA / 300 W / 1024 BTU/h Maximum
Ambient operating
temperature
5–40 °C (41–104 °F)
Ambient non-operating
temperature
-40 to 70°C (-40 to 158 °F)
Humidity below 80% at 31 °C (87.8 °F) Non-condensing
Operating altitude Up to 2000 m (6500 ft)
External cooling max. 0.5 bar (7.2 psi),
max. 50 °C (122 °F)
Waterbath
External pressure 2-12 bar (29-174 psi) Oil-free air or nitrogen
Safety standards: IEC,
CSA, UL
Housing
Installation category II,
Pollution degree 2
All materials are recyclable
For indoor use only
The Agilent 7100 Capillary Electrophoresis System is designed to operate in a typical
electromagnetic environment where RF transmitters, such as mobile phones, should not be
used in close proximity.
