Installing the Instrument
Installing the Instrument
Physical Connection
In general you have to go through the following steps.
1 Unpack the Agilent CE instrument and position it in a suitable location on
your bench, see “Unpacking the Agilent CE Instrument” on page 54.
2 Connect the cables at the rear of the Agilent CE instrument.
3 Install the bottles in the replenishment system, see “Preparing the
Replenishment System if Needed” on page 111.
WARNING
Module is partially energized when switched off, as long as the power cord is
plugged in.
Repair or maintenance work on the module can lead to personal injuries, for
example a shock hazard, when the cover is opened and the module is connected to
the power.
• Ensure that line power cord is disconnected before setting up your Agilent CE
instrument.
