Agilent Technologies Bravo Platform

A Accessories and platepads
Installing and setting up a Vacuum Filtration Station
124
Bravo Platform User Guide
Connecting and configuring the Agilent VARIO Vacuum Pump
The following figure shows the Agilent ME4C NT VARIO Vacuum Pump.
Figure
Agilent ME4C NT VARIO Vacuum Pump
For detailed instructions about the VARIO pump, see the manufacturer’s Instructions
for use, provided with the pump.
The following figure shows the connections for a Vacuum Filtration Station that uses
the ME4C NT VARIO Vacuum Pump.
Figure
Vacuum Filtration Station connections for ME4C NT VARIO Vacuum Pump
Item Name Description
1 Vacuum
Filtration Station
Contains a vacuum port on that base that connects to
the tubing.
CVC 3000
1
2
3
4
5
6
7
8
9
