Agilent Technologies Bravo Platform

9
1 Introduction
Connection panel description
Bravo Platform User Guide
Connection panel description
Bravo rear connection panel
The following figure and table describe the connection panel at the rear of the Bravo
Platform.
Figure
Connection panel on back of Bravo Platform
412 3
00220
Bravo
Back
220c
Item
Feature Description
1 Ethernet port Connects the Ethernet card in the controlling computer
to the Bravo Platform.
