A Accessories and platepads
Bravo accessories overview
104
Bravo Platform User Guide
Bravo accessories overview
Description
You can add accessories to the Bravo Platform to enhance existing functions and
facilitate operation. The accessories and platepads include:
Accessory Description See…
Alignment Station Positions 1536-well microplates for
precise pipetting and ST tip boxes
for precise tips-on operations.
The Alignment Station can also be
used for 384-well microplates.
“Installing and
configuring a platepad
or Alignment Station”
on page 140
Autofilling
accessories
Consists of the following:
• Pump Module
• Auto Filling Reservoir, Tip Wash
Station, or Open Wash Tray
• Weigh Station (optional)
“Autofilling
accessories” on
page 175.
Barcode Reader Consists of a platepad with a
barcode reader and a mirror that
can be installed in place of a
platepad at any deck location.
“Setting up the
Barcode Reader” on
page 185
Lid hotel (delidding
option in
Diagnostics)
Enables you to configure a platepad
in the software to accept a lid in a
delidding process. You use
Diagnostics to configure this option.
“Configuring a
platepad for delidding”
on page 139
Filter Plate Holder Provides a location for a filter plate
while awaiting assembly of the
Vacuum Filtration Station and when
disassembling the station.
“Setting up a Trash or
Filter Plate Holder
accessory” on
page 134
Heating Shaking
Station
(Teleshake 95)
Provides heating and fluid mixing
across a microplate. The station
uses the Inheco Single TEC Control
(STC) or Multi TEC Control (MTC).
“Installing a Heating
Shaking Station” on
page 156
Light Curtain Pauses or stops the operation if the
operator reaches into the Bravo
Platform during a run.
G5562A, G5563A Bravo
Platform Safety and
Installation Guide
Magnetic Bead
Accessory
Designed to separate smaller
volumes (up to 350 µL).
“Installing and
configuring a Magnetic
Bead Accessory” on
page 143
