2 Setting up the Bravo Platform
Starting up and shutting down
Bravo Platform User Guide
Starting up and shutting down
About this topic
This topic describes how to start up and shut down the Bravo Platform when you are
operating it as a standalone device. For instructions on how to turn on and turn off the
Bravo Platform when it is integrated into a workstation or system, see the workstation
or system user documentation.
Starting up the Bravo Platform
Always turn off the Bravo Platform before installing or uninstalling a liquid-handling
head. Failure to do so can damage the head electronics.
To start up the Bravo Platform:
1 Ensure that the main power cable and Ethernet are plugged into the connection
panel.
2 Turn on any accessories, for example, Pump Module.
3 Turn on the computer and the monitor, and start the Microsoft Windows operating
system.
4 If you have not already done so, install the liquid-handling head.
5 On the side of the Bravo Platform, press the power switch to the on (|) position.
The front panel status lights turn blue.
Note: If the emergency-stop pendant is pressed or absent, the status lights will
turn red.
Figure
Bravo status lights and power switch
6 Start the VWorks software.
