E Diagnostics quick reference
Gripper tab quick reference
236 Bravo Platform User Guide
Gripper tab quick reference
About this topic
The Bravo gripper can pick up labware and move it from one location to another on
the Bravo deck. If the Bravo Platform includes a gripper, you use the controls on the
Gripper tab to configure the gripper movements.
The red Stop motors button does not perform an immediate stop. The Bravo head
can continue to move in the same direction at the same speed. To perform an
emergency stop, press the red button on the emergency-stop pendant.
Procedures
You can use the Gripper tab to fine-tune the gripper movements using the following
procedures:
• “Verifying the gripper setup” on page 41
• “Using the gripper controls” on page 96
Gripper Teaching area
Gripper Movement area
Control or indicator Description
Labware Specifies the labware to be used during a move
operation as defined in the Labware Editor.
Y offset Specifies the offset to the y-axis teachpoint at each
location to center the gripper about the labware.
Teach Y offset for gripper Calculates the offset from the selected location
teachpoint to where the gripper is and applies it as
the y-offset.
Approach height (mm) Specifies a vertical offset (safe distance) above the
labware.
Approach Moves the gripper to the specified approach height.
Move Moves the gripper to the teachpoint.
Control or indicator Description
Location A
Pick A -> Place B
Specifies the origin and destination locations for the
gripper to move the labware.
Location B
Pick B -> Place A
Specifies the origin and destination locations for the
gripper to move the labware.
