E Diagnostics quick reference
Vacuum Filtration Station task parameters
Bravo Platform User Guide
Vacuum Filtration Station task parameters
About this topic
This topic describes the task parameters for the following:
• Assemble Vacuum task. Directs the robot to pick up the Vacuum Filtration
Station components from designated deck locations and stack them in the
order you specify.
• Disassemble Vacuum. Directs the robot to remove components from the
Vacuum Filtration Station and place them back at the locations specified in the
Assemble Vacuum task.
• Move and Filter Plate. Moves a plate to the Vacuum Filtration Station and turns
on the vacuum.
To use the Assemble Vacuum and Disassemble Vacuum tasks, you must first set
the Robot gripper offset value for the labware that will be placed on the Vacuum
Filtration Station during a protocol run. You set the offset in the Labware Editor.
To run the Vacuum Filtration Station tasks, see “Performing a task using Bravo
Diagnostics” on page 100.
Parameter description: Assemble Vacuum task
Parameter Description
Assembly order The order, from bottom to top, in which you want
to stack the station components. The selections
are:
• Base-Collection plate-Filter plate-Collar
(configuration A)
• Base-Collection plate-Collar (configuration B)
• Base-Collar (configuration C)
For details, see “Installing and setting up a
Vacuum Filtration Station” on page 114.
Vacuum Filtration base The location of the Vacuum Filtration Station
base.
