E Diagnostics quick reference
Pump Reagent parameters
258 Bravo Platform User Guide
Pump Reagent parameters
About this topic
The Pump Reagent task fills or empties a reservoir or wash tray by pumping for a
specified number of seconds. If the reservoir is on a Weigh Station, the pump stops
fluid flow when the target weight is reached. This topic describes the task
parameters.
Parameter descriptions
To run the Pump Reagent task, see “Performing a task using Bravo Diagnostics” on
page 100.
The Pump Reagent task has the following parameters.
Parameter Description
Reservoir mode The action of the task:
• Fill
• Empty
Pump speed The speed, in percent of maximum, at which to
pump the reagent.
Pump on time The duration of time, in seconds, to run the pump:
If the Use weigh station/shelf option is selected,
this value specifies the maximum time (seconds)
to run the pump. If the pump runs for the full
duration without reaching the weigh station/shelf
threshold, an error occurs.
Use weigh station/shelf The option to use the Weigh Station or Weigh
Shelf.
Weigh station/shelf action
threshold
The minimum fluid weight, in percent of the full
weight that was calibrated on the Weigh Station
or Weigh Shelf.
For example, you can set the minimum threshold
at 45% so that when the fluid reaches 45% of the
full weight, fluid starts to pump into the reservoir.
Weigh station stop action
threshold
The maximum fluid weight, in percent of the full
weight that was calibrated on the Weigh Station
or Weigh Shelf.
For example, you can set the stop threshold at
60% so that when the fluid reaches 60% of the full
weight, fluid starts to drain or pump out of the
reservoir.
