D AssayMAP Bravo Platform
AssayMAP Bravo Platform overview
198 Bravo Platform User Guide
AssayMAP Bravo Platform overview
The AssayMAP Bravo Platform can enable high-throughput microchromatography for
small-scale sample preparation. This topic provides an overview of the platform
components.
Hardware components overview
The following figure and table show the components of the AssayMAP Bravo Platform,
which is required for running the AssayMAP protocols.
Figure
AssayMAP Bravo Platform components
Item Required hardware
1 Gripper upgrade
2 Bravo 96AM Head
3 96AM Wash Station
4 Pump Module 2.0 and two carboys
5 96AM Cartridge & Tip Seating Station
6 Risers, 146 mm
7 STC controller
8 Peltier Thermal Station with custom plate nest
9 Thermal plate insert
10 Orbital Shaking Station with Control Unit
