129
A Accessories and platepads
Installing and setting up a Vacuum Filtration Station
Bravo Platform User Guide
8 Starts disassembled configuration only. Select the following:
a In the Location for Vacuum Filtration Collar list, select the deck location at which
the collar is located, and then click Next.
b In the Vacuum Filtration Collar properties table, specify the following, and then
click Next.
9 Click Finish.
Note: If you verified the accuracy of the platepad teachpoint before installing
and configuring the Vacuum Filtration Station, no further adjustment to the
teachpoint should be required.
10 In the Profiles tab, click Update this profile.
Pump Description
Collar type Specify the size of the collar:
Standard (38 mm) or Deep (67.5 mm).
Black gasket on top side
only
If the collar has the blue gasket or two black
gaskets, select No (default).
If you have omitted the black gasket on the
underside of the collar, select Yes.
