A Accessories and platepads
Installing and configuring a platepad or Alignment Station
142
Bravo Platform User Guide
Figure
Setscrew in platepad tab
Configuring the deck location in the software
To configure the deck location in the software:
1 Initialize the profile in Bravo Diagnostics.
2 Click the Configuration tab, and verify that the deck location is configured as a
Standard Platepad.
3 Verify the teachpoint for this location. For instructions, see “Setting teachpoints” on
page 34.
Related information
For information about... See...
Bravo Platform hardware components “Hardware overview” on page 5
Editing teachpoints “Setting teachpoints” on page 34
