Interference Analyzer (SA Mode) - Option 236 113
During playback, choose from the following:
Pause Resume Temporarily halts playback. Then choose from the following:
o Pause Resume Press to continue playing.
o Playback State/Tag Allows you to continue playback from a state tag, or
scroll through the state tags. Enter a value between 1 and the total number
of state tags using the numeric keypad, ▲|▼ arrows, or the rotary knob.
Learn more in About State and User Tags on page 111.
o Playback Trace Activated automatically when Paused. Allows you to
continue playback from a specific trace, or scroll through traces manually.
Enter a value between 1 and the total number of traces using the numeric
keypad, ▲|▼ arrows, or the rotary knob.
Stop Immediately stops playback. Then choose from the following:
o Play Start playback from trace 1.
o Record Resume recording from the last recorded trace.
o Record Playback Setup Return to the setup menu to change Configuration
settings or Close the session.
Recording Configuration
To change Recording Configuration settings:
Press Trace 6
Then Record Playback Setup
Then New Session or Recall an existing session.
Then Recording Configuration
Then choose from the following:
o Record Time Sets the amount of time to record traces. Default is MAX,
which is to record indefinitely. Enter a value between 1s and 1 Ms (million)
seconds using the numeric keypad, ▲|▼ arrows, or the rotary knob. When
set, a timer appears during recording in the lower-left corner which counts
DOWN from the specified time.
o Record Source Sets where, in the FieldFox data flow, data is recorded.
Learn more about Record Source on page 115.
Choose from the following:
o RawMeas Records raw measurement data.
o Trace 1,2,3,4 Records data from the corresponding trace in its current
state.
o Record Interval Sets the amount of time to wait between individual trace
recordings. Default is MIN, which is to wait 0 seconds (record traces as fast
as possible). Enter a value in seconds between 0 (no delay) and 10,000
seconds - about 3 hrs) using the numeric keypad, ▲|▼ arrows, or the rotary
knob.
