Interference Analyzer (SA Mode) - Option 236 105
Interference Analyzer (SA Mode) - Option 236
Option 236 provides Spectrogram display, Waterfall display, and
Record/Playback. .
In this Chapter
Spectrogram and Waterfall Displays ............. 105
Spectrogram Display ........................................ 105
Common Waterfall and Spectrogram Settings107
Waterfall Display .............................................. 108
Record Playback ................................................. 109
About Sessions .................................................. 109
About State and User Tags .............................. 110
How to Record a Session ................................. 112
How to Playback a Session ............................. 112
Recording Configuration ................................. 113
Playback Configuration ................................... 115
Manage Sessions ............................................... 116
Record Playback Example............................... 116
Spectrogram and Waterfall Displays
Spectrogram and Waterfall displays provide a visual history of the measured
spectrum. Each display type can be used to locate intermittent signals or to view
signal levels over time.
Spectrogram is a single horizontal line of color-coded power while Waterfall uses
a 3-D color-coded display. The functional difference between these two displays
is that Spectrogram provides less trace detail than Waterfall display. However, it
also allows more traces to be viewed.
These two displays can NOT be used with Channel Measurements.
NOTE: Although this document refers to past traces as ‘records’ these traces are not
saved in Spectrogram and Waterfall displays. They are only drawn on the
FieldFox screen.
Spectrogram Display
Spectrogram draws the most recent trace record at the top of the stack of
previously-drawn trace records. Drawing the live trace on the display is
optional.
