8 N9912A FieldFox User’s Guide
Overview
Options and Features
The FieldFox may be ordered to include the following options and features:
Options and Features
Learn more
Cable and Antenna Test (CAT) Mode
▪ 2 MHz to 4 GHz (Option 104)
▪ 2 MHz to 6 GHz (Option 106)
Measurements:
▪ Distance-to-fault (DTF)
▪ DTF & Return Loss
▪ Return Loss (dB)
▪ VSWR
▪ DTF (VSWR)
▪ Cable Loss (1-Port)
▪ Insertion loss (2-Port) (Option 110)
CAT Mode on page 20
Transmission Measurement (Option 110)
CAT Mode on page 20
NA Mode on page 40
QuickCal (Option 111)
Built-in cal kit. Industry first!
Cal on page 62
Spectrum Analyzer (SA) Mode
General purpose measurements for basic monitoring and
troubleshooting.
▪ 100 kHz to 4 GHz (Option 230)
▪ 100 kHz to 6 GHz (Option 231)
SA Mode on page 69
▪ Preamplifier for Spectrum Analyzer (Option 235)
On page 76
▪ Interference Measurements (Option 236)
On page 105
Channel Power Meter Mode (Option 311)
No Power Meter required
On page 118
Power Meter Mode (Option 302)
Use with Agilent External USB Power Sensors
Power Meter Mode on
page 118
Network Analyzer (NA) Mode (Option 303)
▪ 2 MHz to 4 GHz (Option 104)
▪ 2 MHz to 6 GHz (Option 106)
▪ Vector 1-port (Standard)
▪ Scalar 2-port (Option 110)
Measurements:
▪ S11 Reflection (several formats)
▪ S21 Transmission (several formats) (Option 110)
▪ A receiver
▪ R receiver
NA Mode on page 40
Vector Voltmeter (VVM) Mode (Option 308)
Measure electrical length
VVM Mode on page 127
