40 N9912A FieldFox User’s Guide
NA (Network Analyzer) Mode
Learn more about NA Mode measurements in the FieldFox Supplemental Online
Help: www.agilent.com/find/fieldsfoxsupport
In this Chapter
Measurement Selection ......................................... 41
Quick Settings ........................................................ 42
Format ..................................................................... 42
Frequency Range ................................................... 44
Scale Settings ......................................................... 44
Electrical Delay ...................................................... 45
Phase Offset ............................................................ 45
Averaging ................................................................ 46
IF Bandwidth .......................................................... 47
Smoothing ............................................................... 47
Single/Continuous ................................................. 47
Resolution (number of points) ............................ 48
Sweep Time ............................................................. 48
Output Power ......................................................... 49
System Impedance ................................................. 49
Port Extensions ...................................................... 50
Velocity Factor ....................................................... 50
S21 Transmission Measurement ......................... 52
Increase Dynamic Range ...................................... 52
See Also
All about Calibration ............................................. 53
Set Markers ........................................................... 135
Use Limit Lines .................................................... 145
Use Trace Math .................................................... 148
Learn how to make 75Ω (ohm) Measurements in the Supplemental Online Help:
www.agilent.com/find/fieldsfoxsupport
NA Mode Settings
Select NA Mode before making any setting in this section.
How to select NA Mode
 Press Mode_.
 Then NA.
