In the following table, Data/Mem shows both pairs of connectors to have the

same 2 dB difference. However, the second pair of connectors have much better

S11 performance (–50 and –52) and the relative significance is shown in the

Data-Mem values.

Values to compare

Data/Mem

Data-Mem

for S-parameters with

20 *log relationship

Data-Mem

for absolute power levels

with 10*log relationship

–10 dB and –12 dB

2 dB

-24 dB

-14 dB

–50 dB and –52 dB

2 dB

-64 dB

-54 dB
