CALCulate:LIMit:{LOWer|UPPer}[:DATA] {<value>|MIN|MAX|DEF}
CALCulate:LIMit:{LOWer|UPPer}[:DATA]? [{MIN|MAX|DEF}]
Sets an upper or lower limit.
Parameter Typical Return
-1.0E+15 to -1.0E-15,
or
0.0 (default)
or
+1.0E-15 to 1.0E+15
+1.00000000E+00
See Example.
l You can assign a lower limit, an upper limit or both. Do not set the lower limit above the upper limit.
l Limit crossing: If a measurement is less than the specified lower limit, bit 11 ("Lower Limit Failed") is set in the
Questionable Data Condition Register. A measurement greater than the specified upper limit sets bit 12 ("Upper
Limit Failed"). See STATus Subsystem Introduction for further information.
l A CONFigure command resets both limits to 0.
l This parameter is set to its default value after a Factory Reset (*RST) or Instrument Preset (SYSTem:PRESet).
CALCulate:LIMit[:STATe]{ON|1|OFF|0}
CALCulate:LIMit[:STATe]?
Enables or disables limit testing.
Parameter Typical Return
{ON|1|OFF|0}, default OFF 0ξ(OFF)ξorξ1ξ(ON)
See Example.
l The instrument clears front-panel indications of limits being exceeded and clears bits 11 and 12 in the
Questionable Data Register when the measurement function changes, or when any of the following commands is
executed:
CALCulate:LIMit:STATe ON
INITiate
MEASure:<function>?
READ?
CALCulate:LIMit:CLEar
*RST
SYSTem:PRESet
l The instrument turns this setting OFF when the measurement function is changed or after *RST or
SYSTem:PRESet.
Agilent Truevolt Series DMM Operating and Service Guide 121
