CALCulate:TRANsform:HISTogram:COUNt?
Returns the number of measurements collected since the last time the histogram was cleared.
Parameter Typical Return
(none) +87
Return the number of measurements used to compute the current histogram:
CALC:TRAN:HIST:COUN?
CALCulate:TRANsform:HISTogram:POINts{<value>|MIN|MAX|DEF}
CALCulate:TRANsform:HISTogram:POINts?[{MIN|MAX|DEF}]
Sets the number of bins between the lower and upper range values for the histogram. Two additional bins always exist:
one for measurements below the lower range and one for measurements above the upper range.
Parameter Typical Return
{10|20|40|100|200|400|MIN|MAX|DEF}, default 100 +100
See Example.
l You can specify the lower and upper range values using CALCulate:TRANsform:HISTogram:RANGe:
{LOWer|UPPer}. Lower and upper range values are computed automatically if
CALCulate:TRANsform:HISTogram:RANGe:AUTO is ON.
l This parameter is set to its default value after a Factory Reset (*RST) or Instrument Preset (SYSTem:PRESet).
CALCulate:TRANsform:HISTogram:RANGe:AUTO{ON|1|OFF|0}
CALCulate:TRANsform:HISTogram:RANGe:AUTO?
Enables or disables automatic selection of the histogram's lower and upper range values.
Parameter Typical Return
{ON|1|OFF|0}, default ON 0(OFF)or1(ON)
See Example.
l ON: the instrument uses the first 1,000 measurements to set the lower and upper range values.
l OFF: the lower and upper range values are specified by CALCulate:TRANsform:HISTogram:RANGe:
{LOWer|UPPer}.
l Setting the lower or upper range value (CALCulate:TRANsform:HISTogram:RANGe:{LOWer|UPPer) disables
automatic selection of the lower and upper range values (CALCulate:TRANsform:HISTogram:RANGe:AUTO OFF).
l The instrument restarts automatic range value selection (if enabled) when INITiate, MEASure? or READ? is
executed.
l This parameter is set to its default value after a Factory Reset (*RST) or Instrument Preset (SYSTem:PRESet).
