25 — I-110G-P unit data sheet
25-8 November 2013 Alcatel-Lucent 7302 ISAM | 7330 ISAM FTTN | 7360 ISAM FX ONT R04.06.02
Edition 01 3FE 55873 AAAA TCZZA
ONT Product Information Guide
Note
(1)
The letter x following a release number denotes either a letter of the alphabet for maintenance releases or digit from 0
to 9 for minor releases.
25.8 I-110G-P power support
An Alcatel-Lucent-approved ac/dc power supply is required. Contact your
Alcatel-Lucent technical support representative for more information about ordering
a power supply.
25.9 I-110G-P functional blocks
Table 25-10 describes the supported interfaces for I-110G-P indoor ONTs.
Table 25-10 I-110G-P indoor ONT interfaces
The single-residence Gigabit Ethernet ONT with POTS and with or without RF
video ports transmit Ethernet packets to one RJ-45 Ethernet port and voice traffic to
one RJ-11 POTS port. This ONT also features fiber optic and power connectors, as
well as a reset button.
GEM ports per indoor
or outdoor ONT
R04.06.40 to R04.06.42 10 12 are present: 10 are available, 2
are reserved for multicast and
debugging
R04.06.3x, R04.06.43, R04.07.40,
R04.07.45
30 32 are present: 30 are available, 2
are reserved for multicast and
debugging
R04.06.45x, R04.00.4x, R04.02.0x,
R04.02.40x, R04.02.41x
30
R04.02.42x 30
T-CONTs per indoor or
outdoor ONT
R04.06.40 to R04.06.42 6 7 are present: 6 are available, 1 is
reserved for OMCI
R04.06.3x, R04.06.43, R04.07.40,
R04.07.45
6
R04.06.45x, R04.00.4x, R04.02.0x,
R04.02.40x, R04.02.41x
15 16 are present: 15 are available, 1
is reserved for OMCI
R04.02.42x 31 32 are present: 31 are available, 1
is reserved for OMCI
ONT or MDU Release
(1)
Maximum Notes
(2 of 2)
ONT category description Interface capacity
POTS
ports
Ethernet
ports
VDSL2 MoCA RF Video HPNA Wi-Fi
Single-residence Gigabit
Ethernet ONTs with POTS
and with or without RF video
(I-110G-P indoor ONTs)
1 1 —————
