Alcatel-Lucent 7330 - NTP 104-1: B-0404 G-B Business ONT Connections

NTP 104 — Replace a B-0404G-B business ONT
Alcatel-Lucent 7302 ISAM | 7330 ISAM FTTN | 7360 ISAM FX ONT R04.06.02 November 2013 NTP 104-3
3FE 55873 AAAA TCZZA Edition 01
ONT Product Information Guide
Figure NTP 104-1: B-0404G-B business ONT connections
4 Disconnect the fiber optic cable from the ONT (DLP 133).
E
TH
1
E
TH
2E
T
H
3
E
T
H
4
DS1 1
DS1 2
DS1 3
DS1 4
PWR
B
AT
FAIL
NTWK
MGMT
23281
Ethernet
(RJ45) ports
DS1 ports
(RJ-48C)
Ground
Power
connector
Fiber optic
connector
