Rockwell Automation Publication 750-UM006C-EN-P - March 2022 141
Configure and Start Up the Drive Chapter 4
4. After the test is complete, click OK.
5. If the motor rotated in the proper direction, click Yes.
6. If the answer is No, see Motor Polarity
on page 141.
Motor Polarity
If the motor did not rotate in the anticipated direction during the Motor and
Feedback Test, choose the Polarity page to correct the polarity.
