Rockwell Automation Publication 750-UM006C-EN-P - March 2022 61
Configure and Start Up the Drive Chapter 4
3. Right-click the Ethernet network in the Controller Organizer and select
New Module to add the PowerFlex 755 drive to the EtherNet/IP
network.
4. In the Select Module Type dialog box, type PowerFlex 755.
5. Scroll through the list and select PowerFlex 755-EENET (for AC drive
via Embedded Ethernet). This is added to the EtherNet I/O card in slot
3 of the Logix rack.
