Amada ML-2050A-CE - Page 128

128
ML-2050A/2051A/2150A
4. Commands
Data No. Item Data Range
02 [FLASH 1] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
03 [FLASH 2] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
04 [FLASH 3] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
05 [
m
SLOPE] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
06 Unused Fixed to 0000
07 [FLASH 1] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
08 [FLASH 2] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
09 [FLASH 3] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
10 Unused Fixed to 0000
11*
[
≃
] on the [SCHEDULE] screen
Approximate laser output energy of the set waveform
0000 – 9999 (×0.1J)
86 Schedule Settings for FLEX ― TIME 01 to 10
Data No. Item Data Range
01 [Point 1] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
02 [Point 2] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
03 [Point 3] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
04 [Point 4] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
05 [Point 5] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
06 [Point 6] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
07 [Point 7] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
08 [Point 8] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
09 [Point 9] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
10 [Point 10] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
11*
[
≃
] on the [SCHEDULE] screen
Approximate laser output energy of the set waveform
0000 – 9999 (×0.1J)
87 Schedule Settings for FLEX ― TIME 11 to 20
Data No. Item Data Range
01 [Point 11] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
02 [Point 12] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
03 [Point 13] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
04 [Point 14] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
05 [Point 15] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
06 [Point 16] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
07 [Point 17] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
08
[Point 18] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
09 [Point 19] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
10 [Point 20] TIME on the [SCHEDULE] screen 000 – 100 (×0.1ms/×0.01ms)
11*
[
≃
] on the [SCHEDULE] screen
Approximate laser output energy of the set waveform
0000 – 9999 (×0.1J)
