4. Commands
129
ML-2050A/2051A/2150A
Chapter 5 Laser Welding by External Communication Control (RS-485 CONTROL)
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
88 Schedule Settings for FLEX ― WATT 01 to 10
Data No. Item Data Range
01 [Point 1] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
02 [Point 2] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
03 [Point 3] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
04 [Point 4] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
05 [Point 5] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
06 [Point 6] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
07 [Point 7] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
08 [Point 8] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
09 [Point 9] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
10 [Point 10] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
11*
[
≃
] on the [SCHEDULE] screen
Approximate laser output energy of the set waveform
0000 – 9999 (×0.1J)
89 Schedule Settings for FLEX ― WATT 11 to 20
Data No. Item Data Range
01 [Point 11] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
02 [Point 12] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
03 [Point 13] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
04
[Point 14] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
05 [Point 15] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
06 [Point 16] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
07 [Point 17] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
08 [Point 18] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
09 [Point 19] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
10 [Point 20] WATT on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
11*
[
≃
] on the [SCHEDULE] screen
Approximate laser output energy of the set waveform
0000 – 9999 (×0.1J)
⇒
Data No.11 is set to the same value for 86, 87, 88, and 89.
95 Laser Power Monitor ― SHOT COUNT, GOOD COUNT, AVERAGE
Data No. Item Data Range
01*
[SHOT COUNT] on the [POWER MONITOR] screen
Total number of outputs until the present
000000000 – 999999999
02*
[GOOD COUNT] on the [POWER MONITOR] screen
Number of outputs of appropriate energy
000000000 – 999999999
03*
[AVERAGE] on the [POWER MONITOR] screen
Average power of output laser light
0000 – 9999 (×0.1W)
