ML-2050A/2051A/2150A
4. Commands
00 Laser Power Monitor ― Energy, number of waveform data, etc.
Data No. Item Data Range
01* Schedule No. of laser power monitor data 00 – 31
02*
[LAMP INPUT PWR] on the [POWER MONITOR] screen
Lamp input power
000 – 999 (×1%)
03*
[ENERGY] on the [POWER MONITOR] screen
Laser Energy
0000 – 9999 (×0.1J)
04*
Number of laser power monitor waveforms
Total number of transmitted data with classification No.
between 00 and 22.
000 – 108
05* Flash pulse width 000 – 100 (×0.1ms)
01 Laser Power Monitor ― Waveform data 000 to 004
: :
22 Laser Power Monitor ― Waveform data 105 to 109
Data No. Item Data Range
01* Schedule No. of laser power monitor data 00 – 31
02* Laser power monitor waveform data 1/5 0000 – 9999 (×0.1kW)
03* Laser power monitor waveform data 2/5 0000 – 9999 (×0.1kW)
04* Laser power monitor waveform data 3/5 0000 – 9999 (×0.1kW)
05* Laser power monitor waveform data 4/5 0000 – 9999 (×0.1kW)
06* Laser power monitor waveform data 5/5 0000 – 9999 (×0.1kW)
⇒
If the pulse width becomes long, the total number of waveform data can be
controlled to 108 or less by extending the measurement interval.
(Example)
* When the pulse width is 00.5 to 05.0 ms, a measured value is sent at intervals
of 0.05 ms.
* When the pulse width is 05.1 to 10.0 ms, a measured value is sent at intervals
of 0.10 ms.
⇒
Since the number of data to be sent each time is limited to 5, it is necessary to
change the classication No. according to the "number of waveform data of the
laser power monitor" sent by "R00 nn 04" to perform repeated reading.
