1. Setting Welding Schedules
63
ML-2050A/2051A/2150A
Chapter 2 Various Settings
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
(2) Check the output energy displayed in " ."
⇒
In " ", the forecast value of laser output energy based on the set output
schedules is displayed. This value is a little di󰀨erent from the actually measured
value (measured value displayed on the POWER MONITOR screen) provided at
laser welding. However, use it as reference.
1
Setting Output Schedules by Flexible Waveform (FLEX)
Set the output time and output value of each point in the range of "Point1" to
"Point20" by "FLEX" and set the laser light output that becomes a exible waveform.
In this example, SCHEDULE No.: #01, peak value: 4.0 kW, Point1: 1.0 ms/90%,
Point2: 1.0 ms/70%, Point3: 1.0 ms/88%, Point4: 1.0 ms/65%, and Point5: 1.0 ms/0%
are set as output schedules.
(1) Press the MENU key to display the SCHEDULE screen.
(2) Move the cursor to "-SCH.#" and press the ON or OFF key to set the SCHEDULE
number.
(3) Move the cursor to "FORM" and press the ON or OFF key to set "FLEX."
(4) Move the cursor to "PEAK" and press the ON or OFF key to set the laser output
peak value.
<Note>
The settable maximum peak value of laser output di󰀨ers depending on the model.
ML-2050A: 4.0 kW / ML-2051A: 2.5 kW / ML-2150A: 6.0 kW
(5) Move the cursor to "Point" and set the laser output time (ms) and laser output
value (%) of each point.
Place the cursor to "▲" or "▼" of "Point" and press the CURSOR key (
r
or
s
).
Then, the screen is scrolled up or down so that the non-displayed Point can be
displayed.
⇒
Set the point in the range of "Point1" to "Point20" and the laser output time in the
range of 0.2 to 10.0 ms. For the laser output value, set the ratio (%) supposing
that the set laser output peak value is 100%.
<Note>
For setting the laser output time, enter the time from the previous Point.
Set the laser output time so as to result in the following value.
0.2 ms ≤ Total of all Point values ≤ 10.0 ms
-SCH.#00 [FORM:FLEX]
≃
0.0J WATER 28˚C
: OFF PEAK=00.00kW REPEAT= 00pps
p
Point1

00.0ms 000.0%

SHOT =0000
Point2 00.0ms 000.0%
Point3

00.0ms 000.0%
Point4

00.0ms 000.0%
q
Point5

00.0ms 000.0%
HV:OFF POSI.BLINK:OFF POSITION:OFF
