110
Datum Key (N/A for 900, Lathe Mode) (Continued)
The DRO displays the following in the message window:
Datum 02
11. Establish a part zero using Absolute Zero Set – F 01.
Datum 2 is set.
12. Move the tool to the corner of part 3 (indicated by the black dot).
13. Press
The DRO displays the following in the message window:
Datum 02
14. Press
The DRO displays the following in the message window:
Datum 03
15. Establish a part zero using Absolute Zero Set – F 01.
Datum 3 is set.
