Axis Coupling
(900, 3-/4-Axis Only) – F 18/F 19 (Continued)
The DRO temporarily displays the following in the message window:
Coup on
The DRO clears the COUP ON message and displays the following in the message
window.
X +
Xi
Z +
zi
indicating the summed
axes.
To turn off axis coupling axis 3 and axis 4:
1. Press
AND/OR
To turn off axis coupling axis 1 and axis 2:
2. Press
The DRO temporarily displays the following in the message window:
Coup off
