152
Relay 1/Relay 2 Setup
(900 With I/O Option Only) – F 38/F 39
F 38 and F 39 allow you to set up the parameters for Relay 1 and Relay 2.
The following procedures for setting up parameters for Relay 1 also can be used to set
up parameters for Relay 2. Substitute F 39 to set up Relay 2.
To set up Relay 1:
1. Press
The DRO displays the following in the message window:
Rela
i off
2. Press
+
_
to toggle Relay 1 ON.
3. Press
The DRO displays the following in the message window:
Cont
close
4. Press
+
_
to toggle contact OPEN.
5. Press
The DRO displays the following in the message window:
Dir
signal
