Relay 1/Relay 2 Setup
(900 With I/O Option Only) – F 38/F 39 (Continued)
6. Press
+
_
to toggle between Direct
Signal and Coincidence
Pulse.
7. Press
If you select Coincidence Pulse, you can change the output time. The available output
times for Coincidence Pulse are:
Coincidence Pulse Output Time
100 ms (default), 500 ms, 1 sec,
2 sec, 3 sec, 4 sec, 5 sec, 10 sec,
30 sec, 1 min, 2 min, 5 min, 10 min
8. Press
+
_
repeatedly to scroll through
the options.
9. Press to select the Coincidence
Pulse output time.
The DRO displays the following in the message window:
Sel axis
