155
Output Test (With I/O Option Only) – F 42
F 42 allows you to test the following available DRO outputs:
q X ZERO OUT
q Y ZERO OUT
q Z ZERO OUT
q W ZERO OUT
q APZ OUT
q RELAY 1
q RELAY 2
If any of these tests fail, contact your local distributor or ANILAM Customer Services.
To start the output tests:
1. Press
The DRO turns on each available output for approximately 1 second. The message
window displays the name of each output test and the beeper sounds a short beep when
each test is complete.
To return to normal operation:
2. Press
