Mode – F 02 (Continued)
Recalling a Part Zero Position
To recall a part zero position activate the RI as follows:
One Axis
1. Press to select the feature.
2. Press the desired axis key.
3. Press
The axis display resets to zero and the RI begins to blink.
All Axes
1. Press to select the feature.
2. Press to select all axes.
The axis displays reset to zero and the RIs begin to blink for each axis.
CAUTION: During the following step, do not change the machine axis travel direction.
This will cause an error.
3. Move the machine axis approximately 1 in. (25.4 mm) in one direction until the
display starts counting.
The value displayed on the axis display indicates the exact distance from the absolute
part zero position.
4. Move the machine axis until the display indicates zero.
Zero indicates the exact absolute part zero position.
