Parameter Settings – F 20 (Continued)
1. Press
+
_
repeatedly to scroll through
the display resolution options
in MM Mode.
2. Press to select the desired display
resolution in MM Mode.
Setting Display Resolution (INCH Mode)
The DRO displays the following in the message window and axis display:
X .0002
ABS
INCH
Resol inch
Coarse Resolution Symbol
This is the display resolution measured in inches for the axis display(s) when the
MM/INCH key has been toggled to INCH Mode only. The axis designation (in this
example, X) is blinking, indicating that you can enter a value. The DRO will default the
same display resolution as the encoder resolution. ANILAM recommends that you use
the same display resolution as you use for the encoder resolution.
NOTE: The DRO turns on the Coarse Resolution Symbol in the axis display(s) if the
selected display resolution is coarser than the encoder resolution.
1. Press
+
_
repeatedly to scroll through
the display resolution options
in INCH Mode.
