68
Parameter Settings – F 20 (Continued)
Setting Display Resolution (Display Degrees in Decimal Mode)
The DRO displays the following in the message window and the axis display:
w .0i
ABS
MM
Resol deg
Coarse Resolution Symbol
This is the display resolution for the axis display(s) when you set the DRO to display
degrees in Decimal Mode only. The axis designation (in this example, W) is blinking,
indicating that you can enter a value. The DRO will default the same display resolution
as the encoder resolution (in this example, .0I Degrees). ANILAM recommends that you
use the same display resolution as you use for the encoder resolution.
The available display options are:
Display Resolution Options
in Decimal Degree Mode
.0005, .001, .002, .005, .01, .02, .05, .1, .2, .5, 1
NOTE: The DRO turns on the Coarse Resolution Symbol in the axis display(s) if the
selected display resolution is coarser than the encoder resolution.
1. Press
+
_
repeatedly to scroll through the options.
To select the display resolution:
2. Press
