Advanced (ADV) Functions Key (Continued)
The DRO displays the following in the message window and axis display 1
BHP DIA
X .0000
To enter the diameter of the bolt-hole pattern – for example, 2.00 in. (50.8 mm):
8. Press
ENT
The DRO displays the following in the message window and axis display 1
X 0
QT HOLE
To enter the number of bolt-hole patterns (maximum 360 holes) – for example, 4:
9. Press
ENT
The DRO displays the following in the message window and axis display 1
BEG ANGLE
X .0000
