iPAM400 – Product Manual
U-0629-0171.doc – Issue: 04 complete, approved
Page 120 of 138
Audio I/O Expansion Module (optional)
1
Audio Inputs ..................................................................................................... 2 x balanced 0 dBu / 14 kΩ impedance
2
(3-way pluggable Wago cage clamp terminal block)
Audio Outputs........................................................................................................................4 x 0 dBu low level outputs
(3-way pluggable Wago cage clamp terminal block)
Auxiliary DC Supply Output ...........................21 V to 38 V depending on AC or DC supply, and battery conditions /T1A fuse
(2-way pluggable Wago cage clamp terminal block)
Audio-CAN/RS485 Port
3
.................................................................................................. standard dual 9-way D connector
Serial Port
4
............................................................................................................1 x RS232 (standard 9-way D connector)
Ethernet Port ........................................................................................................... 1 x 100BASE-T Ethernet (RJ45 socket)
USB Port ............................................................................................................................. 2 x USB 2.0 (USB type A socket)
VGA Port..................................................................................................... 1 x standard VGA port (15-way HD D connector)
Environmental
Temperature Range (storage and operating) ................................................................................................. 0 °C to +40 °C
Humidity Range.......................................................................................................................... 0% to 93% non-condensing
Ingress Protection ......................................................................................................................................................... IP20
Vibration / Impact .................................................................................................................. EN60068-2-6 / EN60068-2-75
Safety and EMC
EMC........................................................................................ EN61000-6-4:2007, EN61000-6-2:2005, EN55103-1/E1:1996
EN55103-2/E5:1996, EN50121-4:2006, ENV50204:1995
Safety ............................................................................................................................................................. EN60065:2002
Dimensions and Weight
Dimensions (H x W x D) ............................................................................. 86 mm x 439 mm x 425 mm (excluding handles)
2U height, 19” rack mounting
Weight
iPAM400 frame only ................................................................................................................................................12 kg
iPAM400 frame + 1 x MX400 .................................................................................................................................17.4 kg
iPAM400 frame + 2 x MX200 .................................................................................................................................17.4 kg
iPAM400 frame + 4 x MX100 .................................................................................................................................18.4 kg
iPAM400 frame + 1 x MX200 + 2 x MX100 .............................................................................................................17.9 kg
1
Future options: Auxiliary Control Module providing either GSM-R (Global System for Mobile communications – Railway) interface,
or DTMF (Dual-Tone Multi-Frequency) interface.
2
One of the audio inputs is not available when the Listen-in function is configured.
3
The Audio-CAN/RS485 port is for ASL use only.
4
The RS232 port is duplicated on the front of the iPAM400 behind the removable front panel.
