iPAM400 – Product Manual
U-0629-0171.doc – Issue: 04 complete, approved
Page 29 of 138
4.2.2 External Cabling Requirements
Signals Cable Description Termination Suggested Type
AC mains supply
1) 5)
1 x 3-core mains standard
cable
Current rating: 6.3 A
IEC320 socket
2)
Suitably rated standard mains
cable
DC supply input
3) 5)
1 x 1-core red
1 x 1-core black
7W2 mixed signal D connector (female) Suitably rated 1-core cable
Auxiliary DC output
1 x 2-core
2-way pluggable Wago cage clamp
terminal (5.08 mm) (male)
Suitably rated 2-core cable
100 V Loudspeaker
Line
5)
1 x 2-core, twisted,
screened
4-way pluggable Wago cage clamp
terminal (5.08 mm) (male)
Suitably rated 2-core cable
ASL Microphone
4)
Various
8-way pluggable Wago cage clamp
terminal (3.81 mm) (female)
Refer to the user
documentation specific to the
microphone being used; see
Table 7 (page 132).
ASL BMB01 Remote
I/O Unit
4) 5)
• Data: 1 x 2-core,
twisted, screened
• Power: 1 x 2-core
• Analogue inputs:
multicore, screened
• Digital inputs:
multicore, screened
• Digital outouts:
multicore, screened
• iPAM400 side:
8-way pluggable Wago cage clamp
terminal (3.81 mm) (female)
• BMB01 side:
13-way screw-in terminal block
Suitably rated foil screened
cable
ANS Sensor
5)
1 x 3-core, screened
ANS is connected to a BMB01 unit, with
no direct connection to the iPAM400.
• ANS side:
Screw-in terminal block
• BMB01 side:
13-way screw-in terminal block
Suitably rated foil screened 3-
core cable
RS232 Serial data cable 9-way standard D connector (female)
As required to connect to the
external device being used.
Ethernet
Normal standard LAN
cable
RJ45 plug CAT5
USB
Normal standard USB
cable
USB type A plug
As required to connect to the
external device being used.
VGA Port
Standard VGA monitor
cable
15-way High Density D connector (male)
As required to connect to the
external device being used.
Audio input on Audio
Expansion Module
1 x 2-core, twisted,
screened
3-way pluggable Wago cage clamp
terminal (3.81 mm) (female)
Suitably rated screened 2-core
cable
Audio output on Audio
Expansion Module
1 x 2-core, twisted,
screened
3-way pluggable Wago cage clamp
terminal (3.81 mm) (female)
Suitably rated screened 2-core
cable
!
!
1) Note that if the amplifiers are connected as a system which is permanently connected to the mains, then an all-
pole mains isolator with a separation of 3 mm in each pole shall be incorporated in the electrical installation.
2) The mains power supply cable must be terminated with the IEC connector provided (BULGIN PX0587) in order for
the retaining clip to fit properly. Spare is available from ASL; see Table 6 (page 116).
3) A pre-assembled battery supply cable (1.5 m length, LSZH cable) can be ordered separately; see Table 6
(page 116).
4) For EMC compliance:
• Screened cables must be used where specified.
• All screen tails must be <3 cm.
5) Fire rated equivalent cables can be used for safety critical applications.
Refer to BS7671:2008 (Requirements for Electrical Installations) or other appropriate local standards for guidelines
on maximum potential cable lengths given the actual installation parameters.
